We have all been there. It is pouring with rain, the wind is howling, and you have just pulled up to your driveway. You are faced with the dreaded choice: sit in the car and wait for it to stop, or make the dash to unbolt the gates, getting soaked in the process.
For one family in Stoke Bishop, this daily annoyance had become too much. They approached Joe's Fencing with a clear brief: they loved the look of their property, but the manual operation of their heavy driveway gates was becoming a burden. They wanted a seamless, secure, and safe automated solution.
Here is how we transformed their home access with a bespoke automated installation.
The Challenge: Heavy Timber and Sloping Ground
Automation isn't as simple as bolting a motor onto a gate. Every driveway presents unique engineering challenges. During our initial site survey, we identified three key factors:
- Gate Weight: The client had beautiful, solid oak gates. While stunning, they were incredibly heavy. Standard motors would struggle to move them smoothly in high winds.
- Aesthetics: The client didn't want bulky machinery ruining the look of the timber. They wanted the mechanism to be as invisible as possible.
- Safety: With young grandchildren visiting and a dog on the property, the system had to be fail-safe to prevent crushing or entrapment.
The Solution: Underground Automation
To meet the aesthetic requirements, we recommended an Underground Automation System. This involves burying the motors in steel boxes flush with the driveway surface, acting as the bottom hinge. It is the most discreet way to automate a gate.
The Installation Process
Phase 1: Groundworks and Drainage
This is the part most people don't see. We excavated the area at the base of the piers to house the foundation boxes. Crucial Detail: Underground motors hate standing water. If the boxes fill up, the motors can fail. We installed a dedicated soakaway and drainage channels from the boxes to ensure that even in a Bristol downpour, the motors would remain dry and operational.
Phase 2: Cabling and Power
We worked with a qualified electrician to run armoured cabling from the house consumer unit to the gate area. We also ran low-voltage cables for the safety features, hiding them neatly within the brickwork and underground ducting so no unsightly wires were visible.
Phase 3: Fitting the Motors and Gates
We installed heavy-duty hydraulic motors capable of moving 800kg leaves. We then re-hung the heavy oak gates onto the new motor spindles. Unlike the old manual hinges, these hydraulic systems act as a lock. When the gate is closed, the hydraulic pressure holds it firm, making it incredibly difficult for an intruder to force open.
Phase 4: The "Safety Sphere"
At Joe's Fencing, we strictly adhere to Gate Safe and DHF guidelines. An automated gate is a powerful machine, and safety is non-negotiable. We installed:
- Photocells: Beams of light across the driveway. If a car (or a child) breaks the beam, the gates stop instantly and reverse.
- Safety Edges: Rubber pressure strips on the edges of the gates. If they touch an obstacle, the motor cuts out immediately.
- Force Testing: Once powered up, we used specialist equipment to measure the "closing force" of the gate, ensuring it met UK legal safety standards.
The Result: Luxury and Peace of Mind
The transformation was seamless. The family now opens their gates with a click of a key fob as they approach the house. We also installed a Video Intercom system connected to their smartphones, allowing them to see delivery drivers and open the gate for parcels even when they aren't home.
The client's verdict? "It has completely changed how we use the driveway. It feels so much more secure knowing the gates close automatically behind us, and not having to get out in the rain is a luxury we now can't live without."
