For many Bristol homeowners, particularly those living in the terraced streets of Bedminster, Southville, and Easton, the side alley is a vital access point. However, it is also a potential weak spot for home security.
We often find that while homeowners spend money on high-tech doorbell cameras and front doors, the side gate is left rotting on its hinges. In this case study, we walk you through a recent installation that transformed a vulnerable side entrance into a secure, stylish barrier.
The Project Brief: The "Wobbly" Gate
We were called to a property in Bedminster where the existing side gate had reached the end of its life. The issues were clear:
- Rot and Decay: The bottom of the gate had rotted away due to contact with the damp pavement, leaving a gap big enough for a fox (or a determined intruder) to crawl under.
- Structural Failure: The gate was a cheap "Z-brace" construction. Over time, the timber had sagged, meaning the owner had to lift the gate physically to get the latch to engage.
- Security Risk: The lock was a simple sliding padbolt with a rusty padlock, which could easily be bypassed.
The client needed a bespoke solution. As is typical with Bristol terraces, the opening was a non-standard width (940mm), meaning an off-the-shelf gate from a DIY store would not fit.
The Solution: Bespoke FLB Timber Gate
We proposed a custom-built Framed, Ledged, and Braced (FLB) gate. Unlike the previous gate, an FLB gate has a full mortise-and-tenon outer frame.
Key Specifications:
- Material: Pressure-treated redwood joinery grade timber.
- Construction: Tongue and groove boarding set into a robust 45mm thick frame. This prevents the "sag" common in cheaper gates.
- Hardware: 18-inch galvanised T-hinges and a Long Throw Gate Lock. This lock allows the gate to be opened with a key from both the front and back—crucial for a side entrance used daily for bike access.
The Installation Process
Step 1: Removing the Old Frame
The old gate was hung on a thin strip of wood attached to the brickwork, which was pulling loose. We removed the entire structure, including the old wall plate.
We installed a new, heavy-duty 100mm x 47mm timber wall plate. Using chemical resin anchors, we bonded the studs directly into the brickwork. This ensures that no matter how hard the gate is slammed, the frame will not rattle loose from the house.
Step 2: Hanging the Gate
Because we had measured the opening precisely during the survey, the bespoke gate fit the gap perfectly with the correct tolerances for expansion. We hung the gate using heavy T-hinges, positioning them to support the weight of the timber evenly.
Pro Tip: We always leave a 50mm clearance at the bottom of the gate to allow for gravel or uneven paving, ensuring it swings freely even in winter when the ground lifts slightly.
Step 3: Fitting the Security Lock
Security was the priority. We drilled and fitted the "Premium Long Throw" lock. Unlike a padlock which hangs loose, this bolt shoots deep into the frame. We added a stainless steel escutcheon plate around the keyhole to prevent weather damage and tampering.
Step 4: Weather Protection
To ensure longevity, we applied a generous coat of end-grain preservative to the top and bottom of the gate. We also installed a weather strip (a small timber overlap) on the closing edge to stop people from seeing through the gap between the gate and the post.
The Result: Secure and Stylish
The difference was night and day. The new gate closes with a solid, satisfying "thud" rather than a rattle. The tongue and groove finish offers complete privacy, and the stainless steel lock adds a modern, professional touch to the entrance.
The customer commented: "I use this gate every day to get my bike in and out. Not having to lift it up to close it is a relief, and the new lock feels much safer than the old padlock."
